Step 20: Attach Clicker Phone
Hardware
A: Using the Fort Guide to show location, on the (2601) Lower Jamb beside the Door Assembly install the Phone
Base with 2 (S13) #6 x 5/8” Pan Screws then place the Clicker Phone in the Phone Base. (g. 20.1 and 20.2)
2 x #6 x 5/8” Pan Screw
S13
Other Parts
1 x Clicker Phone Set
Clicker
Phone Base
Fig. 20.2
Fig. 20.1
Inside View
Clicker
Phone
Door
Assembly
2601
2601
S13
