Step 26: Chimney Wall Assembly
Part 2
C: Place the Chimney Wall Assembly centred on top of the Roof Assembly and attach with 2 (S13) #6 x 5/8”
Pan Screws. (g. 26.6 and 26.7)
SCALE:1:50
•Attach Chimney to roof using 2- #6 x 5/8" Pan Screws
WEIGHT:
SHEET 4 OF 5
REV.
DWG. NO.
SIZE
Roof Panel CONNECT A2
SCALE:1:50
•Attach Chimney to roof using 2- #6 x 5/8" Pan Screws
WEIGHT:
SHEET 4 OF 5
REV.
DWG. NO.
SIZE
Roof Panel CONNECT A2
Hardware
2 x #6 x 5/8” Pan Screw
S13
S13
Roof
Assembly
Chimney
Assembly
x 2
Roof
Assembly
Chimney
Assembly
