Step 20: Install Window and Wall Inserts
Part 4 - Large Fort Back Wall
Fig. 20.14
Back Wall
Fig. 20.17
Inside View
MOD Arch
Tight
S0
1 x MOD Arch
Other Parts
1 x Short Half Wall 1.27 x 18.8 x 20-15/16”
Wood Parts
Hardware
7 x #8 x 7/8” Truss Screw
S0
649A
G: In the upper opening of (2677) Narrow Panel on the Back Wall of the Large Fort install 1 MOD Arch using 3
(S0) #8 x 7/8” Truss Screws and 1 (649A) Short Half Wall using 4 (S0) #8 x 7/8” Truss Screws. (g. 20.14, 20.15,
20.16 and 20.17)
Outside View
Fig. 20.15
649A
MOD
Arch
Large Fort
Tight
649A
S0
Inside View
Fig. 20.16
2677
2677
