Cedar Summit Paramount F25040 - Part 7 - Small Fort Back Wall

74 support@cedarsummitplay.com
Step 20: Install Window and Wall Inserts
Part 7 - Small Fort Back Wall
20.27
Back Wall
Tight
649A
S0
Inside View
8 x #8 x 7/8” Truss Screw
2 x Short Half Wall 1.27 x 18.8 x 20-15/16”
Wood Parts
Hardware
S0
Fig. 20.29
649A
L: In the upper right hand opening and lower left hand opening of the Small Fort Back Wall install 2 (649A) Short
Half Walls using 4 (S0) #8 x 7/8” Truss Screws per insert. (g. 20.27, 20.28 and 20.29)
649A
2601
649A
Outside View
Fig. 20.28
Small Fort
