Safe2+ / Safe4 Operation Manual
22 www.cedes.com © CEDES Safety & Automation AG / June 2008
11. Technical Data
Table 6
Description Value Remarks
Profile length 120 ... 2'760 mm Selection table page 19
Operating range
0 ... 9 m
0 ... 18 m, optional 6 or 5 up to 30 m
Resolution 14 mm
Resolution 30 mm
Object detection capability
(Resolution)
14 mm
30 mm
Other resolution on request
Power supply U
sp
24 VDC ± 20 % PELV, IEC 60 204-1
Power supply ripple < 10 % of U
sp
Equipment Class III VDE 0106 part 100
Time for self check when switching
on U
sp
< 3 s
Current consumption < 500 mA No-load operation
Outputs, short circuit proof 2 x PNP, 0.3 A
Max. capacitive load 0.5 µF
Output voltage > U
sp
– 1 Load 0.1 A
Response time t
R-BWS
Selection table Page 17
Connector 7 pins, spacing 3.81 mm WAGO M16
Connection cable
Max length 60 m
Cross section max. 1.5 mm
2
Cable gland
- axial
- radial
M 16
M 12, 5-Pin
Outside diameter of cable
3 ... 6.5 mm
3.5 ... 10 mm
for M12
for M16
Mode of operation Guard only with automatic restart
Safety category Type 2 (Safe2+), Type 4 (Safe4) Self testing
Standards IEC 61496 part1+2
Electromagnetic compatibility
(EMC)
IEC 61 496 part 1
Enclosure rating IP65
Temperature range
0 ... +55°C
-20 ... +60°C
Operation with ILAS
Storage / transport
Relative air humidity 15 ... 95 % Not condensing
Enclosure Aluminum profile 30 x 40 mm
Optical window
Polycarbonate, bonded
Optional: Coated polycarbonate,
scratch resistant
Enclosure treatment Polyester powder coated Silicon free manufactured
ILAS Laser class 2 EN 60 825
Dimensions Dimensions and selection tables Pages 16, 17 + 19
Weight Selection tables Page 19
