Know Your Product
1. Power trigger/Stop
2. MPB (Safety lock)
3. Motor cooling vent
4. Hex key
5. Soft grip
6. Handle release latch
7. Blade lock bolt
8. Auxiliary handle
9. Saw dust exhaust
10. Battery cooling vent
11. Depth adjustment lock
12. Lower blade guard lever
13. Spindle lock
14. Bevel angle lock knob
17. Fence locking knob
18. Fence angle lock knob
15. 45° Bevel cut guide noch
16. Straight cut guide noch
Voltage: 18V
No load speed:
Cutting depth @ 0º:
Weight: 7.3lbs (3.3 kg)
Specifications
3,500 RPM
1
9
/
16” (40mm)
Cutting depth @ 45º:
1 ” (28mm)
Saw Blade Options:
Blade bore:
3
/8” (10mm)
1
/16” (2mm)
Circular Saw - Specifications and Know Your Product
6.1 Circular Saw - Know Your Product
87 10
13
15
11
6 6
16
4
9
1
2
5
12
18
3
6.1
14
17
1
/
8
2
WS1-SB01 - 5 / " (136mm)
5
24 tooth TCT
kerf
5½” (140mm)
18 tooth TCT
0.06" (1.5mm) kerf
WS1-SB02 -
