8 • The CR-150 HD
1. Lens Cap (not shown) 9. Leg Extension Clamp
2. Dovetail Slidebar 10. Latitude Adjustment Screw
3. Declination Lock 11. Focus Knobs
4. Declination Setting Circle 12. Eyepiece
5. Counterweight Shaft 13. Finderscope Bracket
6. Counterweights 14. Finderscope
7. Tripod Leg 15. Tube Mounting Rings
8. Accessory Tray 16. Optical Tube
Figure 2-1
The CR-150 HDThe CR-150 HD
The CR-150 HDThe CR-150 HD
The CR-150 HD
1
2
3
4
5
6
7
9
11
12
13
14
15
16
10
8
