Celestron AstroMaster 114EQ User Manual

4
Figure 1-1 AstroMaster 70 EQ Refractor
1. Telescope Optical Tube 9. Latitude Adjustment Screw
2. Dovetail Mounting Bracket 10. Tripod Accessory Tray
3. R.A. Setting Circle 11. Tripod
4. Star Pointer Finderscope 12. Counterweight Bar
5. Eyepiece 13. Counterweights
6. Focus Knob 14. Equatorial Mount
7. Dec. Slow Motion Cable 15. Dec. Setting Circle
8. R.A. Slow Motion Cable 16. Objective Lens
1
2
3
4
5
7
8
9
6
10
11
12
13
14
15
16

Celestron AstroMaster 114EQ Specifications

General

Aperture	114 mm
Focal Length	1000 mm
Focal Ratio	f/8.77
Mount Type	Equatorial
Optical Design	Newtonian Reflector
Highest Useful Magnification	269x
Lowest Useful Magnification	16x
Limiting Stellar Magnitude	12.8
Resolution (Rayleigh)	1.22 arc seconds
Resolution (Dawes)	1.02 arc seconds
Light Gathering Power	265x
Eyepieces Included	20 mm (50x), 10 mm (100x)
Finderscope	StarPointer
Optical Coatings	Aluminum
Tripod	Steel
Weight	17 lbs
