Figure 1-1 Omni XLT 102 Refractor
1
2
3
4
5
6
7
8
9
10
11
12
(Omni XLT 120 Refractor similar)
1. Optical Tube 7. 1.75" Steel Tripod
2. Tube Rings 8. Accessory Tray/ Leg Brace
3. Finderscope 9. Counterweights
4. Eyepiece 10. Counterweight Bar
5. Equatorial Mount 11. Dovetail Slide Bar
6. Latitude Adjustment Screw 12. Objective Lens Shade
5
