BIO X6 User Manual v. 1.0 173
12.3.2 Printhead overview
Figure 112 Overview of the Thermoplastic Printhead
1. Printhead body
2. Stainless steel cartridge
3. Top cap
4. Insulated locking ring
5. Stainless steel plunger
6. Plunger removal tool
7. Wrench for tightening the cartridge and the nozzle
1
2
6
7
3
4
5
