3. Single part list
seq.
NO.
appellation qt
y
seq.
NO.
appellation qty
1 Main Lid 1 32 Cabinet Triangle Bracket 2
2 Temperature Gauge 1 33 Cabinet bottom panel decoration
strip
1
3 Main Lid Screw 2 34 Door stop screw 2
4 Main Lid rubber stopper 4 35 Swivel Caster 4
5 Warm rack 1 36 Swivel Caster Fixing Plug 4
6 Cast iron grid 415x240mm 2 37 Door handle stopper 4
7 Flame tamer 3 38 Door 2
8 Clamp Spring 4 39 Door handle 2
9 Main Burner 4 40 Lower hinge 2
10 Firebox Back Panel 1 41 Control panel side panel, right 1
11 Grease cup holder 1 42 Gas Connector 1
12 Grease cup 1 43 Gas Connector fixing bracket 1
13 Grease tray 1 44 Main Burner Corrugated Pipe 1
14 Side Burner Lid Hinge Rod 1 45 Main Manifold 1
15 Side burner lid 1 46 Control knob 5
16 Side burner grid 1 47 Control knob base 5
17 Side burner 1 48 Control panel side panel, left 1
18 Side burner insert tray 1 49 Control panel 1
19 Side Burner Injector bracket 1 50 Main burner valve 4
20 Side burner ignition wire 1 51 Side burner valve 1
21 Side Burner Injector 1 52 Inner control panel 1
22 Side Burner Corrugated Pipe 1 53 Control panel left side connect
sheet
1
23 Side burner panel 1 54 Control panel right side connect
sheet
1
24 Side table decoration panel 2 55 Left side
table panel
1
25 Door magnet 2 56 Cast iron plate 415x240mm 1
26 Cabinet front beam 1
27 Cabinet left side panel 1
28 Cabinet back panel 1
29 Cabinet right side panel 1
30 Cabinet bottom panel 1
31 Door axle 2
