WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 6
INSTALLATION INSTRUCTIONS
Step 1: Using a screwdriver loosen the two screws that secure the wall mounting bracket to the top of the
appliance and remove the wall mounting bracket as shown below (Figure 1).
Figure 1
Step 2: Choose a solid and plain wall. Position the mounting bracket where the appliance is to be
installed on the wall and ensure that the bracket is level. Using a pen mark the 4 holes through the 4
holes on the mounting bracket as shown below (Figure 2)
Figure 2
Step 3: Take away the mounting bracket and then drill four 8mm diameter holes on the wall. Insert
plastic wall plug into the drilled holes (Figure 3). If installing the appliance on a solid wood wall there is
no need to drill the holes in the wood and no need for the plastic wall plug.
Figure 3
