WALL-MOUNTED ELECTRIC FIREPLACE/HEATER
BFM EUROPE LTD Page 7
INSTALLATION INSTRUCTIONS
Step 4: Fix the mounting bracket using the four screws supplied (Figure 4).
Step 5: Hang the appliance on the hooks at the bottom of the bracket and push the top of the appliance
into the mounting bracket. Now fix the appliance to the mounting bracket by refitting the two M4×8
screws which were removed in step 1(Figure 5).
Figure 4 Figure 5
Step 6: The Electric fire is supplied with 2 fuel bed options. Firstly remove the 2 cardboard fitments which
hold the fitted fuel bed in place. Depending on the product purchased there will be a second fuel bed
option included.
The Enchant has the option of a log or Coal effect Fuel bed.
The Rapture has the option of a Coal effect fuel bed or loose crystal beads.
Place the desired fuel bed effect into position along the bottom ledge of the screen.
Coal effect fuel bed (set) Log (set)
