Page 6 For technical questions, please call 1-888-866-5797. Item 37772 61593
SAFETY OPERATION MAINTENANCESETUP
Specifications
Max. Voltage 1000Vdc/700rms ac (sine)
DC Voltage Ranges: 200mV/2/20/200/1000V
DC Voltage Accuracy (@200mV-200V) 0.5% of rdg ±1D;
(@1000V) 0.8% of rdg ±2D
AC Voltage Ranges: 200mV/2/20/200/700V
Frequency Range: 40-400Hz
AC Voltage Accuracy (@200mV) 1.2% of rdg ±3D;
(@2-200V) 0.8% of rdg ±3D;
(@700V) 1.2% of rdg ±3D
DC Current Ranges:200μA/2mA/20mA/2A/10A
DC Current Accuracy (@ 200μA-20mA) 0.8% of rdg ±1D
(@200mA-2A) 1.5% of rdg ±1D
(@10A) 2% of rdg ±5D
AC Current Ranges: 200μA/2mA/20mA/2A/10A
Frequency Range: 40-400Hz
AC Current Accuracy (@ 200μA&200mA) 1.8% of rdg ±3D
(@ 2mA-20mA) 1.0% of rdg ±3D
(@ 10A) 3.0% of rdg ±7D
Resistance Ranges: 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ
Resistance Accuracy (@200Ω) 0.8% of rdg ±3D;
(@2K-2MΩ) 0.8% of rdg ±1D;
(@20MΩ) 1.0% of rdg ±2D;
Capacitance Ranges: 2nF/20nF/200nF/2μF/20μF
Capacitance Accuracy (@2nf-20μF) 4.0% of rdg ±3D
Frequency Range: 20KHz
Frequency Accuracy (@20KHz) 1.5% of rdg ±5D
Temperature Range: -20° to 1000°C
Temperature Accuracy (@-20° to 0°C) 5.0% of rdg ±4D
(@ 0° to 400°C) 1.0% of rdg ±3D
(@ 400° to 1000°C) 2.0% of rdg
Sampling Rate 2-3 times/second
Overload Protection Fast-Acting 200mA/250V Fuse
Operating Temperature Range: 32° - 104° F
Display LCD
Battery One 9 V (included)
