Page 5For technical questions, please call 1-800-444-3353.Item 60666
SAFETYOPERATIONMAINTENANCE SETUP
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INSTRUCTIONS section at the beginning of this
manual including all text under subheadings therein before setup or use of this product.
Note: For additional information regarding the parts listed in the following pages,
refer to Parts List and Diagram on page 11.
Functions
Positive
Battery
Cable
Work
Light
Clamp
Power Switch
Voltmeter
Charging
Indicator
Light
12VDC
Charging
Input
Negative
Battery
Cable
Battery
Test Button
Work Light
Switch
12VDC
Outlet
120VAC
Charging
Input
Air Compressor
Switch
Air
Pressure
Gauge
Air Hose
Comparment
Air
Hose
Figure A
