Page 11For technical questions, please call 1-888-866-5797.Item 62374
SAFETYOPERATIONMAINTENANCE SETUP
Parts List and Diagram
Parts List
Part Description Qty
1 12V DC Outlet Cover 2
2
Power Switch Cap 1
3
Negative 12VDC Outlet 2
4
Power Switch 1
5
Positive 12VDC Outlet 2
6
Middle Case 1
7
Lens 1
8
LED Board 1
9
Battery 1
10
LED Lamp Panel 1
11
Positive Battery Cable (Red) 1
12
Handle 1
13
Back Case
1
Part Description Qty
14 Air Hose Compartment 1
15
Air Compressor Switch 1
16
Compressor Meter Fixture 1
17
Compressor Hoop 1
18
Internal Adaptor (120VAC) 1
19
Adaptor Stator 1
20
Compressor 1
21
Negative Battery Cable (Black) 1
22
Main Circuit Board 1
23
USB Cap 1
24
Front Case 1
25
Internal Connection Wire 1
26
AC Power Cable
1
Assembly Diagram
