Center 340022 - Thermostat Installation and Parameters; Install the Thermostat; Thermostat Parameters

Parameters
No Description Settings
3OT
Min. On Time 1- 5min
4LL
Lower Limit 5 - 21 °C
5UL
Upper Limit 21 - 35 °C
9LC
Fail Safe 0 = Disabled
1 = Enabled
10BL
Backlight 0 = Disabled
1 = Enabled
11CL
Clock 0 = 24h
1 = 12h
12DS
Daylight Saving 0 = Disabled
1 = Enabled
13TO
Temp. Offset - 3 / + 3 °C
15SD
Reset Schedule 0
1 = Reset
16FS
Factory Reset 0
1 = Reset
17OP
Optimum Start 0 = Disabled
1 = Optimum Start
18OS
Optimum Stop 0 = Disabled
1 = Enabled
Install the Thermostat
1.2-1.5m
The Thermostat and Receiver Box in this pack
are pre-bound.
!
21.0
1:la
3s
