CENTR 1 - PARTS LIST

Pg. 27V07122023-C5
   
1 TUBE, FRAME LEG, LH 102366 1
2 TUBE, FRAME LEG, RH 102367 1
3 WLDMT, LOWER MAIN FRAME 102368 1
4 PLATE, FOOT 102369 1
5 PLATE, FLOOR 102370 1
6 ASSY, UPRIGHT/SLIDER, LH 102371 1
7 ASSY, UPRIGHT/SLIDER, RH 102372 1
8 TUBE, UPRIGHT SUPPORT, REAR 102373 1
9 WLDMT, UPPER MAIN FRAME 102374 1
10 WLDMT, UPPER CROSSBAR 102375 1
11 ASSY, SLIDER, RH 102376 1
12 ASSY, EXTENSION/PIVOT ARM, RH 102377 1
13 ASSY, ROTATING PULLEY 102378 2
14 BRACKET, WATER BOTTLE HOLDER 102379 1
15 COVER, CROSSBAR 102380 1
16 BOLT, M6 X 1 X 60, SH, BZ 102381 1
17 BUMPER, RUBBER, 50 X 25 102382 2
18 ASSY, TOP PLATE 102383 1
19 GUIDE ROD, HOLLOW 1786mm 102384 2
20 ASSY, DUAL FLOATING PULLEY, CENTR1 102385 2
21 COVER, TOP 102386 1
22 L BRACKET, TABLET MOUNT 102387 1
23 TABLET HOLDER, CENTR 102388 1
24 BOLT, M10 X 1.5 X 70, SH, BZ 102389 10
25 WASHER, FLAT, 11 X 20 X 2, BZ 102390 67
26 NUT, M10 X 1.5, LOCK, BZ 102391 33
27 BOLT, M8 X 1.25 X 20, SH, BZ 102392 8
28 WASHER, FLAT, 8.5 X 16 X 2, BZ 102393 12
29 ASSY, SLIDER, LH 102394 1
30 ASSY, EXTENSION/PIVOT ARM, LH 102395 1
31 WATER BOTTLE HOLDER 102396 1
32 SCREW, M4 X 16, PH, BZ, TYPE A 102397 6
33 WEIGHT STACK PLATE 102398 10
34 WEIGHT PIN 102399 1
35 BOLT, M6 X 1 X 75, SH, BZ 102400 2
36 WASHER, FLAT, 6.4 X 12 X 1.6, BZ 102401 4
37 NUT, M6 X 1,LOCK, BZ 102402 2
38 WRENCH,5mm ALLEN 102403 1
39 WRENCH,6mm ALLEN 102404 1
40 WRENCH,10mm & 17mm 102405 1
41 WEIGHT STACK NUMBERS #1-21 102406 1
42 DOCUMENT, UM, CENTR1 102407 1
43 Hardware pack, CENTR1 (STEPS 1-9) 102408 3
44 CABLE, WEIGHT STACK 102409 1
45 CABLE, PIVOT ARM 102410 2
46 SNAP LINK SL1 SL1 2
47 HANDLE, D 2RDH 2
48 BOLT, M10 X 1.5 X 75, SH, BZ 102411 11
49 BOLT, M10 X 1.5 X 20, SH, BZ 102412 4
50 BOLT, M8 X 1.25 X 35, SH, BZ 102413 2
51 BOLT, M10 X 1.5 X 65, SH, BZ 102414 3
52 WLDMT, BENCH MOUNT CENTR1 102415 1
53 BRACKET, SHROUD, CENTR1 102416 4
54 SHROUD, CENTR1 102417 2
55 ROPE, TRICEP TR1 1
56 ANKLE STRAP AS1 1
57 BENCH, FLB2 FLB2 1
