CENTR 1 - ASSEMBLY INSTRUCTIONS; Step 1 Assembly

Pg. 11V07122023-C5

2626
2424
2525
33
1122
44
2727 2828
(24) BOLT, M10 X 1.5 X 70, SH, BZ, .
(25) WASHER, FLAT, 11 X 20 X 2, BZ, .
(26) NUT, M10 X 1.5, LOCK, BZ, .
(49) BOLT, M10 X 1.5 X 20, SH, BZ, .
(25) WASHER, FLAT, 11 X 20 X 2, BZ, .
HARDWARE REQUIRED:
1
4
2
3
25
24
26
49
25
ASSEMBLY
