SKU 54877 For technical questions, please call 1-800-444-3353. Page 7
OPERATION
Step 1: Twist the Handle Assembly clockwise to close
the pressure release valve as shown in Figure 3.
Step 2: Maneuver the Floor Jack underneath the vehicle. Check the vehicle’s Owners
Manual for proper jacking points. Do not lift vehicle by the body.
Step 3: Begin jacking by lowering the Handle Assembly as shown in Figure 4.
Step 4: Lift Handle Assembly as high as clearance allows.
Step 5: Repeat Steps 3-4 until vehicle is at desired height. Do not overextend the jack.
HANDLE ASSEMBLY
FIGURE 3
WARNING
Chalk vehicle’s wheels to
prevent rolling while lifting.
SADDLE (#31)
HANDLE ASSEMBLY
Figure 4
