Central Machinery ROUTER WITH FULL SIZE TABLE 91130 User Manual

SKU 91130 For technical questions, please call 1-800-444-3353. Page 24
SAFETY COVER
(10B)
VARIABLE
SPEED ADJ.
(28B)
KEY (8B)
POWER SWITCH
(9B)
FIGURE U
To Turn On The Router Table:
1. Connect the Power Cord/Plug (1B) to the nearest grounded, 120 volt, electrical
outlet.
2. Depress the Key (8B), and lift up on the Safety Cover (10B). Then, depress the
Power Switch (9B) to its “ON” position. (See Figure U.)
3. To turn off the Router Table, simply depress the Safety Cover (10B) to snap it
shut. This pushes the “OFF” button underneath the Safety Cover and cuts off the
power. (See Figure U.)
4. To lock the Power Switch (9B) and prevent unauthorized use, close the Safety
Cover (10B) and remove the Key (8B) by pulling it out. Make sure to store the
Key in a safe location out of reach of children. (See Figure U.)
To Operate The Router Table:
1. Insert and secure the desired Collet (18D, 24D) and router bit.
2. Make all necessary adjustments to the Router Table.
3. Make sure the Power Switch (9B) is in its “OFF” position. Then, connect the
Power Cord/Plug to the nearest grounded, 120 volt, electrical outlet.
4. Depress the Power Switch (9B) to its “ON” position.
