SKU 91130 For technical questions, please call 1-800-444-3353. Page 26
PARTS LIST A
PARTS LIST B
PARTS LIST C
Part # Description Qty. Part # Description Qty.
1A Support Board 2 2 6A Washer (5) 60
2A Support Board 1 2 7A Plastic Lock Nut (M5) 60
3A Screw (M5 x 12) 60 8A Table 3
4A Support Leg 1 4 9A Support Leg 2 4
5A Leg Washer 4
Part # Description Qt
. Part # Description Qt
.
1B Power Cord & Plug 1 18B Plastic Lock Nut (M6) 16
2B Cord Clip 3 19B Corner Washer 4
3B Cord Protector 2 20B Main Table 1
4B Switch Box Base 1 21B Feather Board 1
5B Plastic Nail 2 22B Square Head Bolt (M6 x 30) 8
6B Locking Buckle 1 23B Hex Screw (M6 x 27) 8
7B Plastic Screw (2.9 x 9) 1 24B Nut (M6) 18
8B Key 1 25B Right Side Board 1
9B Power Switch 1 26B Plastic Lock Screw (2.9 x 13) 4
10B Safety Cover 1 27B Switch Box Cover 1
11B Square Head Screw (M6 x 40) 6 28B Variable Speed Adjustment 1
12B Support Leg 2 29B Plastic Screw (3.5 x 13) 4
13B Large Washer (6) 14 30B Power Cord (16AWG) 1
14B Large Lock Knob 4 31B Terminal 2
15B Screw (M6 x 16) 10 32B Press Board 2
16B Washer (6) 8 33B Terminal Block 1
17B Left Side Board 1
Part # Description Qt
. Part # Description Qty.
1C Lower Fence Left End Cap 2 15C Square Head Screw (M6 x 40) 2
2C Lower Fence 2 16C Upper Fence 1
3C Lower Fence Right End Cap 2 17C Locking Piece 4
4C Self-Lockin
Screw
4.8 x 13
6 18C Upper Fence Left End Cap 1
5C Pin 1 19C Screw (M5 x 12) 4
6C Screw (M5 x 25) 1 20C Fence Support Fixing Washer 2
7C Large Washer (5) 8 21C Plastic Lock Nut (M5) 5
8C Fence Lock Knob 6 22C Square Head Screw (M6 x 30) 2
9C Screw (M6 x 16) 6 23C Protector 1
10C Fence Support 2 24C Dust Port Box 1
11C Head Nut 6 25C Plastic Screw (M2.9 x 9) 2
12C Upper Fence Right End Cap 1 26C Dust Port 1
13C Fence Adjusting Knob 4 27C Miter Gauge (Not Shown) 1
14C Feather Board 1
