PARTS LIST D
PARTS LIST E
Part # Description Qty. Part # Description Qty.
1D Screw (M4 x 10) 10 15D Collet Assy. Cover 1
2D Plastic Lock Nut 4 16D Screw (M4 x 12) 4
3D Washer (4) 4 17D Adjustment Board 1
4D End Running Knot 1 18D Collet (1/2”) 1
5D Slip Knot 1 19D Collet Nut 2
6D Snail Knot 1 20D C-Ring 2
7D Block Ring (45) 1 21D Wrench 1
8D Large Spring 1 22D Small Spring 1
9D Slip Groove 1 23D Height Adj. Lock 1
10D Turning Piece 1 24D Collet (1/4”) 1
11D Steel Bead (5) 6 25D Small Washer B 1
12D Locking Piece 1 26D Small Washer C 1
13D Partial Axis 1 27D Adjustment Tool 1
14D Height Adjusting Ring 1 28D Large Washer 1
29D Hex Screws 4
Part # Description Qt
. Part # Description Qt
.
1E Plastic Bolt (M3.5 x 25) 2 19E Mat Knot 1
2E Fan Cover 1 20E Block Ring (37) 1
3E Carbon Brush 2 21E Cover 1
4E Brush Holder 2 22E Spindle Lock Lever 1
5E Insert Piece 4 23E Screw 2
6E Blue Non-Burning Knot 1 24E Rotator 1
7E Connecting Line 1 25E Screw (M4 x 65) 2
8E Motor Shell 1 26E Washer (4) 5
9E Stator Armature 1 27E Bearing Knot 1
10E Spring Washer (4) 9 28E Terminal 2
11E Bearing (608Z) 1 29E Wire 2
12E Block Ring (20) 1 30E Brush Box Knot 2
13E Block Cover 1 31E Clip 1
14E Locking Piece 1 32E Terminal Block 2
15E Wiring Spring 1 33E Washer (4) 1
16E Screw (M4 x 20) 4 34E Earth Line Cover 1
17E Bearing (6904RS) 1 35E Screw (M4 x 8) 1
18E Dust Block Piece 1 36E Tie Strip (88mm) 3
