Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Part Description
1 Screw
2 Spring Washer
3 Bushing
4 Exhaust Cover
5 Washer
6 Screw
7 Spring Washer
8 Cylinder Cap
9 Gasket
10 O-Ring 36.3x2.5
11 O-Ring 54.3x3
12 Spring
13 Valve
14 O-Ring 40.2x2.3
15 Valve Seal
16 Valve Seal
17 Stopper Washer
18 Washer
19 O-Ring 43.3x3.5
20 Piston Assembly
21 Cylinder
22 O-Ring 50.5x2.5
23 Cylinder Seal
24 Bumper
25 Protective Piece
26 Soft Spacer
27 Body
28 O-Ring 46x1.3
29 Restrictive Washer
30 O-Ring 8.3x1.8
31 Nose
32 Screw
Part Description
33 Bracket
34 Spring
35 Depth Adjuster
36 Safety
37 Spring Pin
38 Safe Bracket Guide
39 Trigger Valve Guide
40 O-Ring 12.8x1.9
41 O-Ring 14.3x1.9
42 O-Ring 6.4x1.5
43 Trigger Valve Stem
44 Trigger Valve Guide
45 O-Ring 12.3x1.9
46 Washer
47
Grey Full-sequential
Trigger
47a
Red Contact Trip
Trigger
48 Trigger Spring
49 Spring Pin
50 Feed Hook
51 Washer
52 Feed Hook Pin
53 Torsion Spring
54 Piston
55 O-Ring 24.3x2.8
56 Piston Bumper
57 Spring
58 Cover
59 Locking Washer
60 Screw
61 Spring Pin
Part Description
62 Handle
63 Washer
64 Catch
65 Pin
66 Protector
67 Spring
68 Latch
69 Pin
70 Stopper
71 Taper Spring
72 Block Plate
73 Spring Washer
74 Screw
75 Nut
76 Washer
77 Connecting Plate
78 Support
79 Bracket
80 Screw
81 Screw
82 Nail Canister
83 Pin
84 Adjuster Bushing
85 Adjuster Stem
86 Adjuster Plate
87 Spring Pin
88 Adjuster Nut
89 Canister Cover
90 Soft Grip Sleeve
91 O-Ring 48.5x2.5
92 End Cap
93 Air Inlet
