Part Description Qty
1 Hex Bolt 1
2 Bolt Sleeve 1
3 Air Deflector 1
4 Hex Bolt 6
5 Spring Washer 6
6 Cylinder Cap 1
7 Gasket 1
8 O-Ring 1
9 Head Valve Spring 1
10 O-Ring 1
11 O-Ring 1
12 O-Ring 1
13 Head Valve 1
14 O-Ring 1
15 Collar 1
16 O-Ring 1
17 O-Ring 2
18 Cylinder 1
19 O-Ring 1
20 Driver 1
21 Bumper 1
22 Cap Gasket 1
23 Housing 1
24 Guide Gasket 1
25 Pin 2
26 Guide Seat 1
27 Adjusting Gasket 1
28 Safety Spring 1
29 Adjusting Seat 1
30 Pin 2
31 Steel Ball 2
32 Position Spring 2
33 Depth Knob 1
34 Push Stem 1
35 Hex Bolt 2
36 Safety Guide Sleeve 2
37 Safety 1
38 Safety Tip 1
39 O-Ring 1
40 O-Ring 1
41 Valve Seat 1
42 O-Ring 1
43 O-Ring 1
44 O-Ring 1
45 Valve Sleeve 1
46 Valve Spring 1
Part Description Qty
47 O-Ring 2
48 Valve Stem 1
49 O-Ring 1
50 Trigger Seat 1
51 Trigger Spring 1
52 Pin Sleeve 3
53 Retainer 2
54 Pin 1
55 Cover Latch 1
56 Moveable Cover 1
57 Fixed Cover 1
58 Hex Bolt 2
59 Pin 2
60 Cover Pin 2
61 Pin 2
62 Position Spring 1
63 Isolation Bar 1
64 Drive Guide 1
65 Pin 1
66 Pusher 1
67 Pusher Stem 3
68 Movable Magazine 1
69 Pusher Spring 3
70 Connection Bolt 2
71 Position Seat 1
72 Latch Spring 1
73 Latch 1
74 Hex Bolt 2
75 Fixed Magazine 1
76 Guide Bar 1
77 Insert Bar 1
78 Hex Bolt 4
79 Hex Bolt 2
80 Fixed Seat 1
81 Spring Washer 1
82 Flat Washer 1
83 Locknut 1
84 Trigger Pin 1
85 Trigger 1
86 Trigger Lever 1
87 Pin 1
88 Grip 1
89 End Cap 1
90 Air Inlet Plug 1
91 Plug Cap 1
Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
