12
ASSEMBLY
is responsible for providing a suitable foundation & rubber
foot mounting where necessary.
HIGH ALTITUDE APPLICATIONS
Refer to the engine manufacturer’s recommendations for
operation of engines at high altitudes.
DANGER!
Under no circumstances should a compressor be
used in an area where toxic, volatile, or corrosive
agents are used or stored near the compressor.
CAUTION!
Unusual noise or vibration indicates a problem. Do
not operate the compressor until the source has been
identified and corrected by a qualified technician.
Fig. 2
WASHER
SCREW
RUBBER FOOT
NUT
ASSEMBLING THE RUBBER FOOT
See Figure 2.
Mount the rubber foot as shown in figure.
Tighten firmly with an open-end wrench (not included)
to secure it in position.
