Page 16 For technical questions, please call 1-800-444-3353. SKU 67696
68149
MOTOR & PUMP PARTS LIST
Part Description Qty
001 Motor & Pump Housing 1
002 Cylinder 1
003 Pump Head 1
004 Crankshaft 1
006 Valve Plate Assembly 1
008 Connecting Rod 1
019 Shoulder Washer 1
023 Filter 1
030 Bearing 6001 2RS 1
041 Connecting Rod Cover 1
045 C-Clip 12 UNI 7435 1
046 Fan 1
062 Cylinder Head Gasket 1
064 Head Gasket Plate 1
078 Piston Ring 1
Part Description Qty
126 Belt 1
531 Screw M5 x 16 TT 1
548 Valve Plate 2
549 Valve Blade 2
550 Gasket Valve Plate 1
602 Bearing 6001 2Z 1
603 Screw 5 x 16 1
604 Washer 6 x 12 x 1.5 1
605 Lower Cover 1
606 Upper Cover 1
607 Screw Parker 3.9 x 13 4
610 Screw M6 x 35 4
611 Nut M6 4
612 Bearing 6203 2Z 1
