Page 14 For technical questions, please call 1-800-444-3353. Impact Wrenches
Part Description Q’ty
1 Motor Housing 1
2 Spring Pin (2x20) 1
3 Air Inlet 1
4 Trigger 1
5 O-Ring (4x1) 1
7 Exhaust Diffuser 1
12 O-Ring (50*1.5) 1
13 Ball Bearing (6001zz) 1
14 Rear End Plate 1
15 Rotor 1
16 Rotor Blade 6
17 Spring Pin (3x8) 2
18 Cylinder 1
19 Front End Plate 1
20 Ball Bearing (EE4) 1
21 Air Regulator 1
22 O-Ring (38.5x2) 1
23 Spring 1
24 Steel Ball (9/64″) 1
Part Description Q’ty
25 Anvil Bushing 1
27 Spring Pin (3x6) 1
28 Hammer Case 1
30 O-Ring (48*1) 1
31 Gasket 1
32 Washer 1
33 Hammer Cage 1
34 Hammer 2
35 Hammer Pin 2
36 Anvil (1/2″) 1
37 O-Ring (6.5x2) 1
38 Retaining Ring 1
39 Screw (M6*20) 4
41 O-Ring (20.35x1.78) 1
42 Valve Spring 1
43 Valve Stem 1
44 Rubber Spacer 1
45 O-Ring (15.7*1.7) 1
47 Mufer 1
68424 Parts List
