SKU 99612 For technical questions, please call 1-800-444-3353. Page 12
and place new batteries in correct
polarity positions matching the old/
used batteries.
4. NOTE: Always dispose of old, used
batteries in accordance with all local,
state and federal regulations. NEV-
ER incinerate batteries. NEVER mix
old and new batteries.
5. Replace the Switch (37) by threading
it onto the top of the Angle Head (26).
PLEASE READ THE FOLLOWING
CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR
HAS PROVIDED THE PARTS LIST AND
ASSEMBLY DIAGRAM IN THIS MANUAL AS
A REFERENCE TOOL ONLY. NEITHER THE
MANUFACTURER OR DISTRIBUTOR MAKES
ANY REPRESENTATION OR WARRANTY OF
ANY KIND TO THE BUYER THAT HE OR SHE
IS QUALIFIED TO MAKE ANY REPAIRS TO THE
PRODUCT, OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT.
IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT
ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED
AND LICENSED TECHNICIANS, AND NOT BY
THE BUYER. THE BUYER ASSUMES ALL RISK
AND LIABILITY ARISING OUT OF HIS OR HER
REPAIRS TO THE ORIGINAL PRODUCT OR
REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
______________________________.
Note: If product has no serial number,
record month and year of purchase
instead.
Note: Some parts are listed and shown for
illustration purposes only, and are not
available individually as replacement
parts.
PARTS LIST
No # DESCRIPTION Q’TY
1
Inlet 1
2
End Cap 1
3 Housing
1
4 Control Lever
1
5 Spring Pin
1
6 Bushings
1
7 Valve
1
8 O-Ring
1
9 Spring
1
10 Speed
1
11 O-Ring
1
12 O-Ring
1
13 Valve Screw
1
14 Ball Bearing
2
15 Rear End Plate
1
16 Ball
3
17 Cylinder
1
18 Rotor
1
19 Vanes
4
20 Bushings
1
21 Front End Plate
1
22 Ball Bearing
2
23 Nipple
1
24 Bevel Gear
1
25 Nut
1
26 Angle Head
1
27 Bevel Gear
1
28 Key
1
29 Chuck Casing
1
30 Bearing Cap
1
31 Collet
1
32 Clamp Nut
1
33 O-Ring
1
34 O-Ring
1
35 Wrench 11MM
1
36 Wrench 17MM 1
37 Switch (ON/OFF) 1
38 LED 1
39 LED Seat 1
40 Batteries 3
To Next Page
