CLEAHMI21 EXTERNAL HMI, CLEAHMI21-BASE - MOUNTING INSTRUCTIONS
Manufactured for and on behalf of the Environmental & Energy Solutions Division of Honeywell Technologies Sàrl, Rolle, Z.A. La Pièce 16, Switzerland by its Authorized Representative:
CentraLine
Honeywell GmbH
Böblinger Strasse 17
71101 Schönaich, Germany
Phone +49 (0) 7031 637 845
Fax +49 (0) 7031 637 740
info@centraline.com
www.centraline.com
Subject to change without notice
MU1Z-0988GE51 R0616B
4: SCREW-MOUNTING ONTO WALL (4A + 4B + 4C) 4A: DRILL HOLES (a) + INSERT DOWELS (b)
164
Ø 6
bb
a a
MIN. 35
MAX. 140
MAX. 65
OPTIONAL
4B: POSITION CLEAHMI21-BASE + CABLE (a / a' / a'') 4C: INSERT SCREWS (a) + CABLE (2B) + INSERT HMI (b)
a
a‘
a‘‘
a a
b
