VI-4
Section VI - PARTS LIST (cont’d)
REF. PART NO.
NO. NUMBER DESCRIPTION REQ'D
-- 0904797 BODY ASSEMBLY 84CA/90W DUAL (cont'd)
68 0400351 #8-32 HEX NUT & STAR WASHER ZP 4
69 0400382 5/16"-18 NYLOK HEX NUT ZP 4
70 0400398 3/8"-16 NYLOK HALF-NUT ZP 24
71 0400421 5/8"-11 NYLOK HEX NUT ZP 12
72 0400451 1/4" FLATWASHER ZP 4
73 0400482 3/8" HELICAL LOCKWASHER ZP 2
74 0400508 5/8" HELICAL LOCKWASHER ZP 8
75 0400567 1/4" RIVET BTT 84 SS 4
76 0400579 SPRING PIN, 3/8" X 4" ZP 2
77 0701956 SCREW, OUTER CROSSTUBE RET, FI 4
78 0703640 WASHER, THRUST (NYLATRON) 2
79 0708529 HOSE, RETURN 3/4" I.D. X 36" 1
80 0713913 SHAFT, BOOM PIVOT - EB4 1
81 0801952 LEG, SHIPPING 2
82 0803906 BOOM TRUNION PIVOT 2
83 0803957 TUBE, BOOM HOSE WELDMENT 1
84 0803994 BODY WELDMENT 1
85 CZ15 RUBBER GROMMET, 1/2" 3
86 DE1716 5/32" X 1/4" DOME HEAD 4
-- 0900923 VALVE ASSEMBLY - 3 & 4 SPOOL
87 0300010 VALVE, 3 SPOOL CONTROL 1
88 0300011 VALVE, 4 SPOOL CONTROL 1
89 0300041 FITTING, CONNECTOR 8MJ-8MB 4
90 0300044 FITTING, CONNECTOR 6MJ-8MB 9
91 0300052 FITTING, ELB 8MJ-10MB90 2
92 0300055 FITTING, HOSE BARB 12C4-12MP 1
93 0300286 FITTING, HP CARRY-OVER 1
94 0301375 FITTING, ELB STR 12MB-12FP90 1
95 0301388 FITTING, ELL 8MJ-8MB90 1
96 0301470 FITTING, ELB 6MJ-8MB90 1
97 0301547 FITTING, ELB 8MJ-12MB90 1
98 0301696 FITTING, ELB 6MJ-6FJX90 7
99 0301780 FITTING, CONNECTOR 8MJ-12MB 1
100 0400140 3/8"-16 X 4" HHCS GR5 ZP 6
101 0400392 3/8"-16 NYLOK HEX NUT ZP 6
