IIIA-1
Section IIIA - OPERATIONAL FUNCTIONS
WHEEL LIFT
3A.1 Your new CENTURY EB-4 / 6500 Wheel Lift is totally hydraulic. It
receives its power from the truck engine by means of a Power
Take-Off/Pump combination attached to the vehicle transmission.
Since the pump is attached directly to the PTO, no drive line or
universal joints are required.
3A.2 The hydraulic pump may be mechanically or electrically engaged
by the PTO knob or the PTO switch in the truck cab.
THE PUMP IS DESIGNED TO RUN ANY FUNCTION
AT NORMAL IDLE SPEED. DO NOT OVER-REV ENGINE.
3A.3 Each function of your CENTURY EB-4 / 6500 Wheel Lift can be
controlled from either of the dual control stations located at the rear
of the wrecker body. See Figure 3A.1.
FIGURE 3A.1
