CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 4
TABLE OF CONTENTS
1. Warranty Information P2
2. Safety Instructions P3
3. Table of Contents P4
4. General Description P5
5. General Features P5
6. Electrical and Panel Specifications P6
7. Application Timing P7,8
8. Mechanical and Environmental Specifications P9-13
9. Mechanical Rendering P14
10. OSD Navigation P13-20
11. Burn-In Mode P20
12. A/D Controller Board P21
13. A/D Controller Board Pin Description P22-27
14. A/D Controller Schematic Power P28
15. A/D Controller Schematic Scaler P29
16. A/D Controller Schematic Panel Interface P30
17. A/D Controller Schematic D-SUB DVI Input P31
18. A/D Controller Schematic Key Button, IR Receiver P32
19. A/C to DC Power Supply, CPM2201A P33-34
20. 24V 2-Lamp Inverter, CPM2236A P35-36
21. 24V 4-Lamp Inverter, CPM2253A P37-38
22. 24V 6-Lamp Inverter, CMP2469 P39-40
23. 12V 4-Lamp Inverter, CPM2237A P41-42
