CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 26
13. A/D Controller Board Pin Description
CN9 AUDIO
PIN FUNCTION
1 AMPLIFIER POWER
2 AMPLIFIER POWER
3 AMPLIFIER POWER
4 VOLUME CONTROL
5 MUTE
6 STBY
7 GROUND
8 GROUND
CN10 LCD DVI-D
PIN FUNCTION PIN FUNCTION
1 RX2-_IN 16 HOT PLUG DETECT
2 RX2+_IN 17 RX0-_IN
3 GROUND 18 RX0+_IN
4 NC 19 GROUND
5 NC 20 NC
6 DDC-SCL 21 NC
7 DDC-SDA 22 GROUND
8 NC 23 RXC+_IN
9 RX1-_IN 24 RXC-_IN
10 RX1+_IN C1 NC
11 GROUND C2 NC
12 NC C3 NC
13 NC C4 NC
14 DVI +5V C5 GROUND
15 GROUND C6 GROUND
