CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 23
13. A/D Controller Board Pin Description
CN2 24VDC INPUT
PIN FUNCTION
1 +24 VDC
6 GROUND
4 GROUND
3 +24 VDC
2 +24 VDC
5 GROUND
CN3 TOUCH POWER
PIN FUNCTION
1 +12VDC
2 +5VDC
3 GROUND
CN5 GPIO, UART
PIN FUNCTION
1 +5VDC
2 GROUND
3 DI
4 DO
5 GPIO
6 GPIO
