CERONIX 15, 17, 19, 20, 22 INCH LCD MONITOR SPECIFICATION AND SERVICE MANUAL 6
6. Electrical and Panel Specifications
Panel
TFT Active Matrix VA (Vertical Alignment)
TFT Active Matrix TN (Twisted Nematic)
Viewable Size
15”, 17”, 19”, 20”, 22”
Native Resolution
15” 1024x768; 17”, 19” 1280x1024; 20” 1600x900; 22” 1680x1050
Aspect Ratio
15” 4:3; 17”, 19” 5:4; 20” 16:9, 22” 16:10
Pixel Size (mm)
0.297(15”), 0.264(17”), 0.294(19”), 0.2768(20”), 0.282(22”)
Brightness (Typical)
250 cd/m
2
Contrast Ratio
500:1 –3000:1
Response Time (Sum of Tr, Tf in mS)
5-20
Colors Supported
16.7 Million
Viewing Angle
178° in Horizontal and Vertical Directions (VA) 170°H, 165°V (TN)
Interface
Analog & Digital
Input Connectors
RGB 15-Pin D-Sub, DVI-D
Signal Frequency
15.5-80KHz Horizontal, 56-75Hz Vertical
Power/Voltage (XX05-LCD)
25-35W, 90 - 264VAC, 50/60Hz
Voltage (XX07-LCD)
12Vdc, 24Vdc
Voltage (XX08-LCD)
24Vdc
Voltage (XX09-LCD)
5Vdc, 12Vdc, 24Vdc
