GENERAL DESCRIPTION
INTRODUCTION
This meter is a rectifier type, permanent-magnet moving coil
instrument for measuring DC voltage, AC voltage, DC current ,
resistance, decibels and for testing battery strength.
1. Pointer
2. Zero set control
3. 0 adjuster knob
4. Selector switch
5. "-" jack
6. "+" jack
7. Scale
1
2
3
4
56
Figure 1
7
2
INTRODUCTION
