model no. 052-0059-8 | contact us 1-800-689-9928
INSTRUCTION
There are five scales:
The upper scale is for resistance measurements.
The second scale " " is for the measurements of DC voltage,
AC voltage ( except AC 12 V range ), and DC current.
The third scale is only for AC voltage measurements of the AC
12 V range.
The fourth scale "dB" is for decibels.
The fifth scale "BATT" is for battery test.
SCALE INSTRUCTION
Figure 2
Common Markings
for Voltage and
Current Scales
