* : ON= active when the switch is closed (+ BATT)
OFF= not active when the switch is opened (GND)
TESTER
MHYRIO UNIT
BATTERY VOLTAGE: level of battery voltage measured with the key switch ON.
VALVES SUPPLY: level of voltage at the positive valve supply (0-VB).
CAN POT EVP: single proportional valve current setpoint, received by the canbus
(% of the current supplied to the valve).
CAN POT GROUP 1: group 1 proportional valves current setpoint, received by canbus
(0-100 % of the current supplied to the lifting, proportional % for the
lowering valve).
CAN POT GROUP 2: group 2 proportional valves current setpoint, received by the canbus
(0-100 % of the current supplied to the tilt box)
CAN POT GROUP 3: group 3 proportional valves current setpoint, received by the canbus
(0-100 % of the current supplied to the side-shift box)
CAN POT GROUP 4: group 4 proportional valves current setpoint, received by the canbus
(0-100 % of the current supplied to the 4° Way box)
INPUT 0: state of DIGITAL INPUT 0:
ON / +VB : active input, closed switch
OFF / COND : non-active input, open switch
INPUT 1: state of DIGITAL INPUT 1:
ON / +VB : active input, closed switch
OFF / COND : non-active input, open switch
INPUT 2: state of DIGITAL INPUT 2:
ON / +VB : active input, closed switch
OFF / COND : non-active input, open switch
ANALOG INPUT 1: voltage of the analog input.
not used
