Product details
Product guide – CESAB S200
38
Automatic switch-off
For more information regarding automatic switch-off, see the Service manual.
Feature
A service technician can set the desired time inter-
val for truck switch-off in case the truck is left
unattended. This time can be set to either 4 h or
in the range of 1-20 minutes in increments of one
minute.
Benet
The truck can be optimised for use in special settings. In surroundings with many
people, the time can be set very short to ensure unauthorised persons cannot ope-
rate the truck when the operator sometimes need to leave it unattended to take care
of other tasks, while in settings with no unauthorised people the time can be set to a
longer interval to prevent the truck being switched off before the operator returns.
Creep speed
This feature switches truck travel to inching speed and permits truck travel with
the tiller arm in the upright position. It is activated
by quickly moving the travel direction selector (R)
two times forwards or backwards. When this fun-
ction is engaged, ”SLO” blinks in the display. The
function can be cancelled by once again quickly
moving the travel direction selector (R) two times
in either direction or by 10 seconds of inactivity.
The feature is also disabled if the safety reversing button is actuated. Inching speed
is 1.7 km/h. A service technician can block this feature to prevent inching speed
operation, however, by default the creep speed mode can be activated by the ope-
rator.
Feature
Creep speed enables truck travel at creep speed with the tiller arm in the upright
position and without any need to push buttons.
Benet
The truck can be manoeuvred in very conned areas. Because the function works
without any need to push buttons, the operator has both hands free to steer the
truck.
