CESAB S208L User Manual

Technical information
Product guide – CESAB S200
79
Model S212 S212
Mast Dx Tele Openview. Triplex
Lh (mm) 4150 4500
Battery compartment M L
1)
M L
1)
L
2
measurement, mm 758 808 775 825
x-measurement, mm 639 639 622 622
Drive wheel - front border 150 150 150 150
Wheel base y, mm 1247 1297 1247 1297
Axle - support arm tip, mm 169 169 169 169
Back of forks - support arm tip, mm 808 808 791 791
1) Sideways battery change
Model S214 S214 S214
Mast Dx Free lift. Dx Tele Openv. Tx Free lift
Lh (mm) 4105 4105 4755
Battery compartment M L
1)
M L
1)
M L
1)
L
2
measurement, mm 758 808 758 808 775 825
x-measurement, mm 639 639 639 639 622 622
Drive wheel - front border 150 150 150 150 150 150
Wheel base y, mm 1247 1297 1247 1297 1247 1297
Axle - support arm tip, mm 169 169 169 169 169 169
Back of forks - support arm tip, mm 808 808 808 808 791 791
1) Sideways battery change
Model S212L S212L
Mast Simplex Duplex Tele.
Lh (mm) 1700 4150
Battery compartment M L
1)
M L
1)
L
2
measurement, mm 735 785 753 803
x-measurement, mm 717 717 799 699
x-measurement lifted support arms, mm 658 658 640 640
Drive wheel - front border 150 150 150 150
Wheel base y, mm 1302 1352 1302 1352
Wheel base lifted support arms y, mm 1243 1293 1243 1293
Axle - support arm tip, mm 212 212 212 212
Axle - support arm tip lifted support arms, mm 153 153 153 153
Back of forks - support arm tip, mm 870 870 852 852
1) Sideways battery change
