CESAB S208L User Manual

Technical information
Product guide – CESAB S200
80
Model S212L S212L
Mast Triplex Dx Tele Openview
Lh (mm) 4500 4150
Battery compartment M L
1)
M L
1)
L
2
measurement, mm 778 828 761 811
x-measurement, mm 674 674 691 691
x-measurement lifted support arms, mm 615 615 632 632
Drive wheel - front border 150 150 150 150
Wheel base y, mm 1302 1352 1302 1352
Wheel base lifted support arms y, mm 1243 1293 1243 1293
Axle - support arm tip, mm 212 212 212 212
Axle - support arm tip lifted support arms, mm 153 153 153 153
Back of forks - support arm tip, mm 827 827 844 844
1) Sideways battery change
Model S214L S214L
Mast Dx Tele Openview Triplex
Lh (mm) 4150 4500
Battery compartment M L
1)
M L
1)
L
2
measurement, mm 761 810 778 828
x-measurement, mm 691 691 674 674
x-measurement lifted support arms, mm 632 632 615 615
Drive wheel - front border 150 150 150 150
Wheel base y, mm 1302 1352 1302 1352
Wheel base lifted support arms y, mm 1243 1352 1243 1293
Axle - support arm tip, mm 212 212 212 212
Axle - support arm tip lifted support arms, mm 153 153 153 153
Back of forks - support arm tip, mm 844 844 827 827
1) Sideways battery change
Model S220D S220D
Mast Duplex Tele Dx Tele Openview
Lh (mm) 2100 2100
Battery compartment M L
1)
M L
1)
L
2
measurement, mm 760 760 768 768
x-measurement, mm 932 982 924 974
x-measurement lifted support arms, mm 873 923 865 915
Drive wheel - front border 150 150 150 150
Wheel base y, mm 1542 1592 1542 1592
Wheel base lifted support arms y, mm 1483 1533 1483 1533
Axle - support arm tip, mm 212 212 212 212
Axle - support arm tip lifted support arms, mm 153 153 153 153
Back of forks - support arm tip, mm 1085 1135 1077 1127
1) Sideways battery change
