Product details
Product guide – CESAB S200
27
Product details
Operator environment
The S200 trucks are primarily designed for operators walking with the truck and
not standing on a platform, however, an optional operator platform is available for
all models except S208L
Tiller arm and controls
There are two versions of the tiller arm for the S200 series. One is designed for the
walkie trucks while the other is designed for the platform truck with the operator
riding onboard. Both versions use CESAB's ergonomic handles. On the S210 and
the S208L the handle is slightly smaller than on the other versions. Main compo-
nents and controls are located as follows:
1 Control for lifting and lowering
2 Switch for safety reversing
3 Control for lifting and lowering the support arms
4 Travel direction selector and speed control lever
5 Horn
6 Display
7 Tiller arm and brake
8 Emergency switch-off
9 Creep speed
7
8
6
1
2
3
5
4+9
