Seat Lock
The seat lock is on the left side of the vehicle�
The seat can be removed by inserting the key and turning to
release the lock�
Gear Shift Lever
The gear shift lever
1
is on the left side of the engine�
The exposed length of the screw thread at both ends of the
middle connecting rod is adjustable (the adjustment range is
4mm~12mm);
Loosen the locking nuts at both ends;
Rotate the middle connecting rod to adjust the height of the shift
lever;
Relock the nuts� (Torque: 6N•m)
The vehicle can be driven in track gear�
To shift to the track gear, mount the lower end of the connecting
rod to the front point�
WARNING
1The shift direction of the track gear is opposite to the
international gear�
This function is recommended for trained personnel� Non-
professionals are not allowed to use track gear if they are not
trained or familiar with it�
Riding a vehicle when the rider is unfamiliar with the track gear
can result in serious injury or death�
1
6 6
5 5
4 4
3 3
2 2
N N
1 1
14
2
3
2
D
D
To Next Page
