CLUTCH LEVER FREE-PLAY
Turn handlebar left to the maximum�
Slowly apply the clutch lever until the resistance is evident� Check the free-play distance of the clutch lever
is within the following range�
Free-play: 0�39 in ~ 0�78 in (10 mm ~ 20 mm)
WARNING
If there is no free play for clutch lever, the clutch will start to slip�
Inspect the free-play every time before running the engine�
Set the free-play as stipulated when necessary�
Fine adjustment of clutch lever free-play
Loosen lock nut
1
;
Rotate the adjusting nut
2
for adjustment;
Tighten the lock nut
1
�
2
1
10 mm ~ 20 mm
