CF MOTO CF400ATR-2S User Manual

INTRODUCTION
8
Specication
Item
Specication
CF400ATR-2S CF500ATR-2S CF400ATR-2L CF500ATR-2L
Overall Length
2180 mm 2180 mm 2380 mm 2380 mm
Overall Width
1100 mm 1100 mm 1100 mm 1100 mm
Overall Height
1150 mm 1150 mm 1350 mm 1350 mm
Wheel Base
1260 mm 1260 mm 1480 mm 1480 mm
Minimum Ground Clearance 250 mm 250 mm 250 mm 250 mm
Min. Turning Radius
3500 mm 3500 mm 4000 mm 4000 mm
Basic Weight
358 kg 358 kg 382 kg 382 kg
Engine Model and Type
191Q 191R 191Q 191R
Type
Water - cooling / 4stroke ,SOHC
Bore X Stroke
91 mm×61.5 mm 91 mm×76.2 mm 91 mm×61.5 mm 91 mm×76.2 mm
Displacement
400mL 400mL 495mL 495mL
Compression Ratio
10.3 : 1
Starting Type
Electric start
Lubrication Type
Splashed by pressure

CF MOTO CF400ATR-2S Specifications

General

Brand	CF MOTO
Model	CF400ATR-2S
Category	Offroad Vehicle
Language	English
