MAINTENANCE & LUBRICATION
133
Exhaust spark arrestor
Clean carbon deposits from the spark arrester while the muffler
and exhaust are in normal air temperature.
1. Remove the fasteners
1
.
2. Tap the tailpipe lightly to loosen it and remove the spark
arrester
2
from the muffler.
3. Use a wire brush to remove any carbon deposits from the
spark arrester portion of the tailpipe
3
.
4. Insert the tailpipe into the muffler and align the bolt holes.
5. Install and torque the fasteners to 7.3 ft-lb. (10 N•m).
