MAINTENANCE & LUBRICATION
153
1 Headlamp Fuse 5 Null
2 FAN Fuse 6 Oxygen sensor fuse
3 Start relay 7 Spare fuse
4 Signal,Fuel pump fuse 8 Flash
1
High-Tension lgnition
coil
4
Start Relay
2 Battery 6 ECU
3 Idle Valve 7 Regulator/Rectier
4 Fuse
