FEATURES & CONTROLS
49
Front Diff-lock Switch “LOCK”/”4WD”
To lock the front diff in 4WD, make sure the on-command four-
wheel-drive switch is set to 4WD, stop the vehicle, move the
lever
B
to 2WD/4WD switch, then set the switch
C
to LOCK,
when the front diff is locked, the The 4WDLOCK indicator “
”will display .
NOTE
●When the switch is set to “LOCK”, the front diff-lock indicator
light will flash until the front diff is locked.
●When the indicator light is flashing, turning the handlebar left
and right will help the front gear lock to engage.
●Riding before the front diff-lock is properly engaged (e.g.,
when the indicator light is flashing) will cause the engine speed
to be limited until engagement is complete.
●When the vehicle is in 4WD-LOCK, the maximum traveling
speed is limited to 30 km/h (19 mph). However, if conditions
require full engine power to be available, depress the override
switch to disable the 4WD-LOCK speed limiter.
B
C
