151
MAINTENANCE
Transmission oil maintenance- 1000 engine only
Oil level check (1000)
1. Place the vehicle on a level surface.
2. If the engine was running, wait a sucient amount of time for
the oil to settle and cool.
3. Unscrew the transmission oil dipstick
2
, remove it, and wipe
o with a clean cloth.
4. Insert the dipstick back into the dipstick hole, make the dipstick
threads contact the hole surface without screwing it.
5. Remove the dipstick and check the oil level indication. Maintain
the oil level between the upper and lower indicators.
6. Reinstall the dipstick into the oil ller hole, and hand-tighten it.
Oil change (1000)
1. Place the vehicle on a level surface.
2. If the engine was running, wait a sucient amount of time for
the oil to settle and cool.
3. Place an oil pan under the engine to collect the used oil.
4. Remove the transmission oil drain bolt at the bottom of the oil
ll location and drain the oil.
5. Place a new sealing washer on the drain bolt, then assemble
and tighten the drain bolt to 22 ft-lb. (30 N•m).
6. Add the specified amount of recommended transmission oil,
then reinstall the transmission oil dipstick and hand-tighten it.
NOTE: Transmission oil type –SAE75W-90 GL-5 Capacity - 20 oz.
(0.6L)
MAX
MIN
2
